ScaleBuster’s Water Conditioner Technology
How It Works
The ScaleBuster® is a physical water conditioner that inhibits scale and corrosion. The electrostatic device uses the dielectric characteristics of the special plastics and metallic materials of its construction combined with the hydraulic conditions present during operation to force the precipitation of solid crystals in the water. The ScaleBuster® may be used in a variety of residential, industrial, commercial and municipal applications, including point-of-entry end uses.
- Rather than preventing precipitation of salts, our proprietary device which is a physical conditioner works using a proprietary mechanism which forces the precipitation of these salts.
- Crystals nucleate with non-binding geometry pass through a system with minimal adhesion to the surfaces.
- Water becomes more aggressive (under saturated) and gently “eats” existing lime scale as water is a perfect solute.
The patented, self-cleaning, electrostatic device operates without electrical power and has no moving components. It has been proven in labs, a diverse set of field conditions, and a significant number of commercial installations.
The electrostatic device uses the characteristics of the dielectric and metallic materials of construction and the hydraulic conditions present during operation to temporarily disturb the carbonate/bicarbonate equilibrium reactions and force the precipitation of calcium carbonate crystals in the water. Note that this occurs even when the saturation index for the water indicates that the water does not have a scaling tendency.
HCO3– <– –>H+ + CO3— K2 = 4.68 * 10-11 (pK2 = 10.33 @ 25°C)[1]
[1] Stumm, W. and Morgan, J. Aquatic Chemistry, 3rd edition, 1996, Wiley, p. 152
The small value for K2 indicates that the bicarbonate ion (HCO3-) is normally favored over the carbonate ion (CO3–) at pH values below 10.33 (where the molar concentrations are equal). The electrostatic device disturbs the equilibrium by pushing this reaction to the right – hydrogen ions (protons) are pulled away from the bicarbonate ion leaving more carbonate ions. The spike in carbonate ion concentration pushes calcium carbonate (CaCO3) over its saturation limit and precipitation occurs.
Precipitation of Calcium Carbonate Crystals
The water around the newly created calcium carbonate particles is now unsaturated and seeks to re-dissolve any calcium carbonate it comes in contact with. This includes calcium carbonate scale already present on pipe and heat exchanger surfaces. In fact, scale on pipe and equipment walls tends to dissolve back into solution faster than the newly formed particles, because water flow contact on surfaces is more intense than on particles borne along within the flow.
The form of calcium carbonate created by the electrostatic device is aragonite instead of calcite. Aragonite crystals have an orthorhombic (needle type) structure instead of the trigonal (typically blocky type) structure. Aragonite forms soft scale deposits that are easily brushed from surfaces as opposed to calcite which forms hard scale deposits that are difficult to remove.
Scale Removal From Pipe and Heat Exchanger Surfaces
The advantage of diverting precipitation that adheres to equipment surfaces to that of particulates suspended in the water cannot be overstated. When scale attaches to equipment, it causes more than flow and heat transfer inefficiencies; it also delivers a concentrate of biological nutrients to the surfaces in question. Preventing this “fertilization” of biofilms is an important part of keeping the cooling system in peak operating condition.
How Does Hardness Get Into Water and How Does It Come Out Again?
The dominant components of supermolecular structure of any ground or spring water are calcium (Ca2+) and hydrogen carbonate (HCO3–) ions which result from the decomposition of calcium carbonate (CaCO3) according to the following simple equation:
The hardness of water increases with the number of these ions.
Based on the same but reversed equation, hard water can be softened by separating calcium back to its solid phase (CaCO3). This process occurs, for example, in boiling
hard water. The well-known incrustation (see figure A below – providing a view from an electron microscope) is formed at the phase interface and suspension is formed in the liquid phase – at a greater distance from the phase interface.
Water softening requires a certain amount of power, either heat power, mechanical power, or electric power. The lowest consumption, and therefore the highest efficiency of CaCO3 separation is achieved by electric power, which makes it possible to reverse the course of the above-mentioned reaction. The quantity of electric power must be however sufficient to maintain the thermodynamic water balance.
Consequently,
- CaCO3 molecules in suspension form are formed in water; in open systems these molecules are washed away (see figure B below – providing a view from an electron microscope).
- The liberated carbon dioxide (CO2) in combination with water can dissolve old incrustations, which is accompanied by water hardening.
- If the treated water is not consumed within the specific period of time (typically 24-72 hours), the process of CaCO3 molecule decomposition starts and returns to the original pre-treatment state. The length of the period depends on water alkalinity and concentration of released carbon dioxide (CO2). Water with lower alkalinity returns sooner to the original pre-treatment state than water with higher alkalinity.
The process starts with the formation of carbonic acid (#1) from carbon dioxide and water. At the pH of normal environments this exists as a bicarbonate (#2) which can form together with minerals (from various sources in the ground). In acidic earth, CO2 will dissolve (#3) calcium from limestone and then water picks up the Ca and bicarbonate together forming calcium bicarbonate.
Water temperature increasing promotes carbonate formation as the CO2 is released that can lead to an increase in pH and higher CaCO3 concentrations.
The solubility in water of Calcium carbonate effectively decreases as the temperature rises which means that it readily precipitates out in heating systems.
Any supermolecular structure of water described by a complete chemical decomposition contains not only Ca2+ and HCO3-, but also Mg2+, Na+, Fe2+,… cations (in lower concentrations though) and SO42-, NO3-, Cl–,… anions.
The cation-anion proportion guarantees the mutual balance of their total positive and negative charges under stable conditions, the law of electrochemical neutrality.
The electric conductivity of water depends on the total concentration of cations and anions as electric current carriers. By implication, if electric current is produced in hard water of a particular anion and cation concentration which sets these cations and anions in motion (analogically to Brown motion in water heating), in all probability it results in the highest number of mutual collisions of ions of opposite charges, and the subsequent separation of the highest number of chiefly CaCO3 molecules within the liquid phase. This process is determined by the reversed equation for the above-specified chemical reaction.
Types of Hardness in Water…
- Permanent hardness is hardness (mineral content) that cannot be removed by boiling. When this is the case, it is usually caused by the presence of calcium and magnesium sulphates and/or chlorides in the water, which become more soluble as the temperature increases. Despite the name, the hardness of the water can be easily removed using a water softener, or ion exchange column.
- Temporary hardness is caused by the presence of dissolved carbonate minerals (calcium carbonate and magnesium carbonate). When dissolved, these minerals yield calcium and magnesium cations (Ca2+, Mg2+) and carbonate and bicarbonate anions (CO32-, HCO3-). The presence of the metal cations makes the water hard. However, unlike the permanent hardness caused by sulfate and chloride compounds, this “temporary” hardness can be reduced either by boiling the water, or through the process of lime softening. Boiling promotes the formation of carbonate from the bicarbonate and precipitates calcium carbonate out of solution, leaving water that is softer upon cooling.
Dry Contact Galvanic Anodic Protection
In ScaleBuster® Water Conditioners, the Dry Contact Anode is the main component of a Galvanic Cathodic protection used to protect downstream pipes (and fittings) from corrosion.
The Dry Contact Anode is made from pure Zinc (>99.9% Zn) which has more “active” voltage (more negative reduction potential/more positive electrochemical potential) than the pipe metal downstream. The difference in potential between the two metals means that the galvanic anode corrodes, meaning that the anode material is consumed in preference to the protected piping metal. The ScaleBuster is designed so that the anode should last for many years (depends on the water which runs through the device, of course).
Corrosion is a chemical reaction occurring by an electrochemical mechanism. During corrosion there are two reactions, oxidation (as to Equation No. 1), where electrons leave the metal (and results in the actual loss of metal) and reduction, where the electrons are used to convert water or oxygen to hydroxides (Equations No. 2 and 3).
In most environments, the hydroxide ions and ferrous ions combine to form ferrous hydroxide, which eventually becomes the familiar brown rust (as in Equation No. 4):
Equation No. 4: Fe2+ + 2OH− → Fe(OH)2
The loose red rust or hematite (Fe2O3) is transformed into black magnetite (Fe3O4) by responding to the Zinc electron. The Magnetite is harder and helps extend life expectancy of the steel piping by factor 2-3 (as in Equation No. 5):
Equation No. 5: 2Fe2O3 + e−→ 2Fe3O4
The transformed magnetite reverts to its formal state, iron, by keeping on receiving the Zinc electron.
As corrosion takes place, oxidation and reduction reactions occur and electrochemical cells are formed on the internal surface of the metal pipe so that some areas will become anodic (oxidation) and some cathodic (reduction). Electric current will flow from the anodic areas into the electrolyte as the metal corrodes. Conversely, as the electric current flows from the electrolyte to the cathodic areas the rate of corrosion is reduced. (In this example, ‘electric current’ is referring to conventional current flow, rather than the flow of ions).
As the metal (steel, in most cases) continues to corrode, the local potentials on the surface of the metal will change and the anodic and cathodic areas will change and move. As a result, in these ferrous metals, a general covering of rust is formed over the whole pipe internal surface, which will eventually consume all the metal. This is rather a simplified view of the corrosion process, because it can occur in several different forms.
The ScaleBuster Cathodic Protection works by introducing the Dry Contact Zinc Anode, so that all the current will flow from the Dry Contact Anode and the metal to be protected becomes cathodic in comparison to the anode. This effectively reduces and stops the oxidation reactions on the metal pipe by transferring them to the galvanic anode of the ScaleBuster, which will be sacrificed in favor of the piping under protection.
For this to work there must be an electron pathway between the Dry Contact Anode and the metal to be protected (e.g., direct contact) and an ion pathway between both the oxidizing agent (e.g., water) and the anode, and the oxidizing agent and the metal to be protected (e.g., the pipe), thus forming a closed circuit.
Advantages and Disadvantages of
ScaleBuster Dry Contact Galvanic Cathode Protection
- No external power sources is required.
- ScaleBuster water conditioners are relatively easy to install.
- Lower voltages and current mean that risk of causing stray current interference on other structures is very low.
- ScaleBuster systems require less monitoring than impressed current cathode protection systems.
- Relatively low risk of overprotection.
Main Disadvantages
- Current capacity is somewhat limited by anode mass and self-consumption at low current density.
- Lower driving voltage means that the anodes may not be efficient in high-resistivity environments.
ION ScaleBuster ® and CORROSION
Corrosion occurs because metals tend to oxidize when they come in contact with water,
resulting in the formation of stable solids.
What problems does corrosion cause?
Corrosion can cause higher costs for a water system due to problems with:
- decreased pumping capacity, caused by narrowed pipe diameters resulting from
corrosion deposits; - decreased water production, caused by corrosion holes in the system, which reduce
water pressure and increase the amount of finished water required to deliver a gallon of
water to the point of consumption; - water damage to the system, caused by corrosion-related leaks;
- high replacement frequency of water heaters, radiators, valves, pipes, and meters because of corrosion damage; and
- customer complaints of water color, staining, and taste problems.
How is corrosion diagnosed and evaluated?
The following events and measurements can indicate potential corrosion problems in a water system:
Consumer complaints: Many times a consumer complaint about the taste or odor of water is the first indication of a corrosion problem. Investigators need to examine the construction materials used in the water distribution system and in the plumbing of the complainants’ areas.
Corrosion indices: Corrosion caused by an inappropriate layer of calcium carbonate deposition in the system can be estimated using indices derived from common water quality measures. The Langelier Saturation Index (LSI) is the most commonly used measure and is equal to the water pH minus the saturation pH (LSI = pH water – pH saturation). The saturation pH refers to the pH at the water’s calcium carbonate saturation point (i.e., the point where calcium carbonate is neither deposited nor dissolved). The saturation pH is dependent upon several factors, such as the water’s calcium ion concentration, alkalinity, temperature, pH, and presence of other dissolved solids, such as chlorides and sulfates. A negative LSI value indicates potential corrosion problems.
Sampling and chemical analysis: The potential for corrosion can also be assessed by conducting a chemical sampling program. Water with a low pH (less than 6.0) tends to be more corrosive. Higher water temperature and total dissolved solids also can indicate corrosivity.
Pipe examination: The presence of protective pipe scale (coating) and the condition of pipes’ inner surfaces can be assessed by simple observation. Chemical examinations can determine the composition of pipe scale, such as the proportion of calcium carbonate, which shields pipes from dissolved oxygen and thus reduces corrosion.
How can system corrosion be reduced?
Corrosion in a system can be reduced by changing the water’s characteristics, such as adjusting pH and alkalinity; softening the water with lime; and changing the level of dissolved oxygen (although this is not a common method of control). Any corrosion adjustment program should include monitoring. This allows for dosage modification, as water characteristics change over time.
pH adjustment: Operators can promote the formation of a protective calcium carbonate coating (scale) on the metal surface of plumbing by adjusting pH, alkalinity, and calcium levels. Calcium carbonate scaling occurs when water is oversaturated with calcium carbonate. (Below the saturation point, calcium carbonate will redissolve; at the saturation point, calcium carbonate is neither precipitated nor dissolved. The saturation point of any particular water source depends on the concentration of calcium ions, alkalinity, temperature, and pH, and the presence of other dissolved materials, such as phosphates, sulfates, and some trace metals.
It is important to note that pH levels well suited for corrosion control may not be optimal for other water treatment processes, such as coagulation and disinfection. To avoid this conflict, the pH level should be adjusted for corrosion control immediately prior to water distribution, and after the other water treatment requirements have been satisfied.
Lime softening: Lime softening (which, when soda ash is required in addition to lime, is sometimes known as lime-soda softening) affects lead’s solubility by changing the water’s pH and carbonate levels. Hydroxide ions are then present, and they decrease metal solubility by promoting the formation of solid basic carbonates that “passivate”, or protect, the surface of the pipe.
Using lime softening to adjust pH and alkalinity is an effective method for controlling lead corrosion. However, optimum water quality for corrosion control may not coincide with optimum reduction of water hardness. Therefore, to achieve sound, comprehensive water treatment, an operator must balance water hardness, carbonate levels, pH and alkalinity, as well as the potential for corrosion.
Dissolved oxygen levels: The presence of excessive dissolved oxygen increases water’s corrosive activity. The optimal level of dissolved oxygen for corrosion control is 0.5 to 2.0 parts per million. However, removing oxygen from water is not practical because of the expense. Therefore, the most reasonable strategy to minimize the presence of oxygen is to:
- exclude the aeration process in the treatment of groundwater,
- increase lime softening,
- extend the detention periods for treated water in reservoirs, and
- use the correct size water pumps in the treatment plant to minimize the introduction of air during pumping.
What about the use of corrosion inhibitors?
Corrosion inhibitors cause protective coatings to form on pipes. Although they reduce corrosion, they may not totally arrest it. There are several commercially available corrosion inhibitors that can be applied with normal chemical feed systems. Among the most commonly used for potable water supplies are inorganic phosphates, sodium silicates, and mixtures of phosphates and silicates.
Inorganic phosphates: Inorganic phosphate corrosion inhibitors include polyphosphates, orthophosphates, glassy phosphates, and bimetallic phosphates. Zinc, added in conjunction with polyphosphates, orthophosphates, or glassy phosphates, may help to inhibit corrosion in some cases.
Silicates: The effectiveness of sodium silicates depends on both pH and carbonate concentrations. Sodium silicates are particularly effective for systems with high water velocities, low hardness, low alkalinity, and pH of less than 8.4. Typical coating maintenance doses of sodium silicate range from 2 to 12 milligrams per liter. They offer advantages in hot-water systems because of their chemical stability, unlike many phosphates.
Is cathodic protection an option?
Because the corrosion process is the result of an anodic and cathodic process, it can be controlled either by anodic or cathodic reactions. For both anodic and cathodic reactions to take place, electrons and ions must be transferred.
There are two basic methods of applying cathodic protection. One method uses inert electrodes, such as high-silicon cast iron or graphite, which are powered by an external source of direct current.
The second method uses a sacrificial anode. Magnesium or zinc anodes produce a galvanic action with iron, so that the anodes are sacrificed (or suffer corrosion), while the iron structure they are connected to is protected.
Why the Ion ScaleBuster® water conditioner?
The ScaleBuster® device is considered a “slick” design among sacrificial anode devices because its non-stick polyperfluoroethylene (PTFE) treatment surfaces remain remarkably free of occluding build-up debris that can strongly diminish treatment performance. Its treatment surfaces do not collect magnetized rust particles or other conveyed sediments – including any scale solids that the unit induces to form. In not requiring electrical input, the unit can ignore power outages, and avoids possible corrosion factors from insufficiently shielded AC current inputs or poorly rectified DC sources energizing electromagnet units. Stray currents if allowed to spread out onto adjoining pipelines can sponsor electrolytic corrosion and additionally remove scale nucleation sites normally critical for generating essential scale particulates.
One common oversight for assuring successful conditioner application is failing to retain carbonate scale nucleation sites in a unit’s immediate downstream plumbing. For the supersaturated stream from the conditioner to grow carbonate particulates in the limited 2 to 3 seconds that the flow remains supersaturated, carbonate scale surfaces need to be present to foster immediate rapid particle production. Even when plumbing is grounded, excess stray AC voltages can corrosively scour nucleate sites off critical pipeline areas to yield an adverse non-treatment result.
Favourably again, the ScaleBuster® includes an internal zinc anode block that provides a stream of negative charges along all electrically attached plumbing so far as such pipeline continues to be of a mono-metallic composition; that is, for example, a stainless steel insert could shield off the zinc protection for extensions of iron pipe. In any event, the cathodic protection as afforded by the zinc anode strongly assists the conditioner to create the needed particle formation.
Properly installed, a water conditioner, such as the advantageous ScaleBuster® can reduce scale and corrosion by three basic mechanisms:
- Calcium carbonate scale formation on submerged surfaces is managed by the conditioner treatment pre-emptively forcing carbonate scale out of the water in suspended particulate form that leaves the liquid phase of the water much less saturated with scale-forming solutes.
- Calcium carbonate precipitates which typically concentrate organic nutrients (TOC) towards stimulating biofouling corrosion are drawn away from pipeline contact and into the suspended scale particles where biological activities can have little consequence upon pipe surfaces. (Up to 80% of water TOC can be absorbed out of the water leaving a cleaner water phase to in contact with pipeline walls).
- The internal zinc anode block in a ScaleBuster® unit provides local cathodic corrosion protection even as it promotes its basic anti-scaling efficiency.
Typical water quality complaints which might be due to corrosion
Source: U.S. Environmental Protection Agency
